| MACHINE MODEL | DL-1512 |
|---|---|
| XYZ LINEAR GUIDE WAYS | X/Y/Z Axis Roller type |
| DISTANCE BETWEEN TWO COLUMNS | 1400 mm |
| X TRAVEL | 1500 mm |
| Y TRAVEL | 1220 mm |
| Z TRAVEL | 800 mm |
| SPINDLE NOSE TO TABLE SURFACE | 150~950 mm |
| TABLE SIZE | 1500x1100mm |
| T-SLOT (Q’TY X SIZE X DIST) | 7x22x150 mm |
| TABLE LOAD CAPACITY | 3000 kgs |
| SPINDLE TRANSMISSION | Direct type |
|---|---|
| SPINDLE TAPER | BT40 |
| SPINDLE SPEED | 10000rpm (DL-1512P)
15000rpm (DL-1512M) |
| SPINDLE MOTOR | 11/15 kW |
| ATC CAPACITY | 24 tools |
