| TRAVEL | ||
|---|---|---|
| X TRAVEL | 630 mm | |
| Y TRAVEL | ||
| Z TRAVEL | ||
| SPINDLE CENTER TO TABLE SURFACE | 50~680 mm | |
| SPINDLE NOSE TO TABLE SURFACE | 130~760 mm | |
| TABLE | ||
| TABLE SURFACE TO FLOOR | 1100 mm | |
| TABLE SIZE | 400×400 mm | |
| T-SLOT/BOLT SPEC. | 24-M10P1.5×20 mm | |
| TABLE LOAD CAPACITY | 400 kgs | |
| INDEX PRECISION | 0.001° | |
| SPINDLE | ||
| SPINDLE TAPER | BT40 | |
| SPINDLE SPEED | 10000rpm | |
| FEEDRATE | ||
| SPINDLE MOTER(CONT/30 MIN) | 15/18.5 kW | |
| 3-AXES CUTTING FEEDRATE | 1-10000 mm/min | |
| 3-AXES RAPID FEEDRATE | 36 M/min | |
| 3-AXES MIN. SETTING UNIT | 0.001mm | |
| ATC | ||
| TOOLS | 40 tools | |
| APC | ||
| NUMBER OF PALLETS | 2 pcs | |
| METHOD OF PALLET CHANGE | Rotary | |
| PALLET CHANGE TIME | 8 sec | |
